AT-FS970M Series Version 2.3.1.0 Web Interface User’s Guide

329

Enabling sFlow on the Switch

Before enabling the sFlow feature on the switch, you must configure sFlow
on the ports. The port configurations cannot be edited if the sFlow feature
is enabled. For how to configure sFlow on the ports, see “Configuring
sFlow on a Port” on page 327.

To enable the sFlow feature on a switch, do the following:

1. Hover the cursor over the Discovery & Monitoring tab.

The Discovery & Monitoring tab is displayed. See Figure 143 on
page 324.

2. From the Discovery & Monitoring tab drop-down menu, select

sFlow.

The sFlow page is displayed with the Port Configurations tab selected.
See Figure 144 on page 324.

3. Use the pull-down menu next to the Status field to select “Enabled.”

4. Click Apply.

5. Click SAVE to save your changes to the startup configuration file.
