AT-FS970M Series Version 2.3.1.0 Web Interface User’s Guide

157

Displaying the Hosts List

To display the IGMP Hosts List, do the following:

1. Hover the cursor over the Switching tab.

The Switching tab is displayed. See Figure 56 on page 151.

2. Hover over IGMP and then move the cursor to the right to select IGMP

Snooping.

The IGMP Snooping page is displayed with the Configuration tab
selected by default. See Figure 57 on page 152.

3. Click the Hosts List tab.

The Hosts List page is displayed. See Figure 59.

Figure 59. IGMP Snooping Page with Hosts List Tab

The following settings are displayed:

Group Address— Multicast address of the group.

VLAN ID— VLAN ID of the host node.

Port ID— Port of the host node. If the host node is on a port trunk,
this field displays the trunk ID number instead of the port number.

Host IP— IP address of the host node.

IGMP Version— IGMP versions used by the host node.

Time to Expiry— Number of seconds remaining before the host
node is timed out if it does not send an IGMP report.
