Chapter 25: LLDP and LLDP-MED
288
Configuring LLDP on a Port
To assign LLDP to a port, do the following:
1. Hover the cursor over the Discovery & Monitoring tab.
The Discovery & Monitoring tab is displayed. See Figure 122 on
page 284.
2. From the Discovery & Monitoring tab, hover over LLDP and then
select Port Configurations on the right.
The LLDP Port Config page is displayed. See Figure 124.
Figure 124. LLDP Port Config Page
3. Select Edit next to the port that you want to modify.
The Modify LLDP Port Configuration page is displayed. See Figure
125 on page 289.
