Chapter 25: LLDP and LLDP-MED

286

Holdtime Multiplier— Enter a holdtime multiplier value. The
transmit interval is multiplied by the holdtime multiplier to give the
Time To Live (TTL) the switch advertises to the neighbors. The
range is 2 to 10. The default value is 4.

Non Strict Med TLV Order Check— Check the checkbox to set
the switch to accept LLDP-MED advertisements, even if the TLVs
are not in the standard order, as specified in ANSI/TIA-1057. This
configuration is useful if the switch is connected to devices that
send LLDP-MED advertisements in which the TLVs are not in the
standard order. By default, this checkbox is not selected.

Notification Interval— Enter a notification interval. This is the
minimum interval between LLDP SNMP notifications (traps). The
range is 5 to 3,600 seconds. The default value is 5.

Reinit— Enter a reinitialization delay. This is the number of
seconds that must elapse after LLDP is disabled on a port before it
can be reinitialized. The range is 1 to 10 seconds. The default
value is 2.

Tx Delay— Enter a transmission delay. This is the minimum time
interval between transmissions of advertisements due to changes
in LLDP local information. The range is 1 to 8192 seconds. The
default value is 2.

Total Neighbors— Indicates the number of LLDP neighbors the
switch has discovered on all its ports.

Neighbors Last Update— Indicates the time since the LLDP
neighbor table was last updated.

5. Click Apply.

6. Click SAVE to save your changes to the startup configuration file.
