AT-FS970M Series Version 2.3.1.0 Web Interface User’s Guide
115
Adding an LACP Trunk
To create an LACP trunk, do the following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 24 on page 65.
2. From the Switching tab, hover over Link Aggregation.
For an example of the Link Aggregation selection, see Figure 43 on
page 113.
3. Move the cursor to the right and select LACP.
The LACP Trunks page is displayed. See Figure 44 on page 113.
4. From the LACP Trunks page, click Add.
The Add LACP Trunk page is displayed. See Figure 45.
Figure 45. Add LACP Trunk Page
