Chapter 18: 802.1x Port-based Network Access

214

Disabling 802.1x Port-based Authentication on a Port

To disable 802.1x port authentication on a port, do the following:

1. Hover the cursor over the Security tab.

The Security tab is displayed. See Figure 68 on page 182.

2. From the Security tab drop-down menu, select 802.1x Port

Authentication.

The 802.1x Authentication page is displayed. See Figure 79 on page
207.

3. Click Edit next to the port that you want to modify.

The Modify 802.1x Authentication page is displayed. See Figure 80 on
page 208.

4. Use the pull-down menu next to the Port Role field to select “None.”

5. Click Apply.

6. Click SAVE to save your changes to the startup configuration file.
