AT-FS970M Series Version 2.3.1.0 Web Interface User’s Guide

117

Modifying an LACP Trunk

To modify the LACP Trunk settings, see the following procedure:

1. Hover the cursor over the Switching tab.

The Switching tab is displayed. See Figure 24 on page 65.

2. From the Switching tab, hover over Link Aggregation.

For an example of the Link Aggregation selection, see Figure 43 on
page 113.

3. Move the cursor to the right and select LACP.

The LACP Trunks page is displayed. See Figure 44 on page 113.

4. From the LACP Trunks page, click Edit next to the Aggregator ID that

you want to change.

The Modify LACP Trunk page is displayed. See Figure 46.

Figure 46. Modify LACP Trunk Page
