Chapter 15: Power Over Ethernet (PoE)
172
Displaying PoE Port Settings
To display a list of the PoE port settings, do the following:
Note
The PoE pull-down menu item appears only when you are
accessing a PoE featured switch.
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 65.
Figure 65. Switching Tab
2. From the Switching tab drop-down menu, select PoE.
A list of PoE settings on the ports is displayed. See Figure 66 on page
173.
