Chapter 19: Setting IPv4 and IPv6 Addresses

220

Changing an IPv4 Address

To display a list of the IPv4 interfaces, do the following:

1. Hover the cursor over the Layer 3 tab.

The Layer 3 tab is displayed. See Figure 83 on page 218.

2. From the Layer 3 tab drop-down menu, select IPv4 Interfaces.

A list of IPv4 interfaces is displayed. See Figure 84 on page 218.

3. From the IPv4 Interfaces page, click Edit next to the VLAN ID that you

want to modify.

The following page is displayed. See Figure 86.

Figure 86. Edit IP Address Configuration Page

4. Change the following fields as needed:

IP Address— Enter the IP address that the VLAN is assigned to.

Subnet Mask— Enter the subnet mask of the IPv4 address.

VLAN— Select the VLAN to manage the IP address.
