Allied Telesis AT-FS970M Series User Manual
Page 271
AT-FS970M Series Version 2.3.1.0 Web Interface User’s Guide
271
Removing a VLAN Interface from the RIP Configuration
To remove a VLAN interface from the RIP configuration, do the following:
1. Hover the cursor over the Layer 3 tab.
The Layer 3 tab is displayed. See Figure 112 on page 265.
2. From the Layer 3 tab drop-down menu, hover the cursor over RIP,
move the cursor to the right, and select Configuration from the RIP
drop-down menu.
The RIP configuration page is displayed. See Figure 113 on page 265.
3. Click Delete next to the VLAN that you want to remove.
