AT-FS970M Series Version 2.3.1.0 Web Interface User’s Guide
239
Assigning an ACL to Ports
Before assigning ACLs to ports, ACLs must be available on the switch. To
create an ACL, see “Creating an ACL” on page 235.
To assign an ACL to ports, do the following:
1. Hover the cursor over the ACLs & QoS tab.
The ACLs & QoS tab is displayed. See Figure 91 on page 235.
2. From the ACLs & QoS tab drop-down menu, select Policies/ACLs.
The Policies/ACLs page is displayed. See Figure 95.
Figure 95. Policies/ACLs Page
3. Click Add on the right above the table.
The Traffic Classifiers page is displayed. See Figure 96 on page 240.
