B Appendix - Flamepath
The maximum constructional gap (ic) is less than that required by Table 2 of EN 60079-1:2007 as detailed below:
FLAMEPATH
MAXIMUM GAP
(MM)
MINIMUM WIDTH
(MM)
COMMENT
1. Between component drawings
BRT2MPXALBPAN and BRT2MPXTAPINF
0.249 25.4 Cylindrical joint sup-
ported by bearings
2. Between component drawings
BRT2MPXALBTP and BRT2MPXBUT
0.245 26.8 Cylindrical joint sup-
ported by bearings
3. Between component drawings
BRT2MPXALBTS and BRT2MPXBUT
0.245 26.8 Cylindrical joint sup-
ported by bearings
4. Between component drawings
BRT2MPXALWIP and BRT2MPXBUST
0.249 25.3 Cylindrical joint sup-
ported by bearings
Tab. 23
