14.4 Communications
Configuration through OSD
2 half-duplex serial RS485 interfaces or full-duplex
RS422
Firmware updating from console in remote mode
(only VIDEOTEC MACRO and PELCO D protocols)
Up to 999 units, addressable by means of dip-
switches
Integrated fiber optic video/data transceiver
(optional):
- 10bit PCM
- Half-duplex RS485
- Multi Mode/Single Mode
IP Streaming Module (optional)
- MPEG4 compression
- Compatible with ONVIF 1.01
- Compatible with VMS Milestone XProtect suite
- LAN 10/100 Mbit/s RJ45 interface
- Resolutions: Full D1 (720x576) @30fps, VGA
(640x480), CIF (352x288), QCIF (176x144)
14.4.4 Protocols
AMERICAN DYNAMICS, ERNITEC, PANASONIC, PELCO
D, VIDEOTEC MACRO*
The product may be interfaced with devices not manufactured by
VIDEOTEC. It is possible that the interface protocols have changed or
are in a different configuration from earlier tested units by VIDEOTEC.
VIDEOTEC recommends a test prior to installation. VIDEOTEC will
not be liable for any installation costs or lost revenues in the event a
compatibility problem will occur.
*AMERICAN DYNAMICS, ERNITEC, PANASONIC, PELCO are registered
trademarks.
14.4.5 Environment
Indoor / Outdoor
Operating temperature: -40°C / +60°C (-40°F / +140°F)
Installation temperature (not operative): -40°C /
+60°C (-40°F / +140°F)
Surge immunity: up to 2KV line to line, up to 4KV line
to earth (Class 4)
14.4.6 Certifications
ATEX (EN 60079-0: 2009, EN 60079-1: 2007, EN 60079-
31: 2009)
- b II 2 G Ex d IIC T6 T
a
-40°C to +60°C Gb
- b II 2 D Ex tb IIIC T85°C T
a
-40°C to +60°C Db
- IP66
IECEx (IEC 60079-0: 2007, IEC 60079-1: 2007, IEC
60079-31: 2008)
- Ex d IIC T6 T
a
-40°C to +60°C Gb
- Ex tb IIIC T85°C T
a
-40°C to +60°C Db
- IP66
14.4.7 Brackets and adapters
MPXWBA AISI 316L stainless steel wall
bracket
MPXCW AISI 316L stainless steel corner
adapter module
MPXCOL AISI 316L stainless steel pole
adapter module
MPXWBTA AISI 316L stainless steel
parapet or ceiling mounting
bracket
14.4.8 Accessories
OCTEX3/4C Cable gland with gasket EX
3/4" NPT, unarmoured cable
IECEX-ATEX-GOST
OCTEXA3/4C Cable gland with gasket EX
3/4" NPT, armoured cable
IECEX-ATEX-GOST
OCTEXB3/4C Barrier cable gland 3/4" NPT,
unarmoured cable IECEX-ATEX-
GOST
OCTEXBA3/4C Barrier cable gland 3/4" NPT,
armoured cable IECEX-ATEX-
GOST
OCTEX3/4 Cable gland with gasket EX
3/4" NPT, unarmoured cable
ATEX
OCTEXA3/4 Cable gland with gasket EX
3/4" NPT, armoured cable ATEX
14.4.9 Package
Unit weight:
MPXT
31kg (68lb)
