Videotec MAXIMUS MPXT - Manual (Page 64)

EN - English - I
nstruc
tions manual
62
9.7.3.1 Controlling PTZ movements
To set movement control via the control panel or via
mouse, proceed as follows:
Select the Setup / Setup Camera menu and select the
PTZ tab.
Select the first unit, or the one you want to configure,
from the Media Source list.
Check the Enable PTZ box.
Click on Apply.
This will automatically set the VIDEOTEC Macro
protocol at 38400 baud.
Repeat the procedure for the other units to be
controlled, directly from the PTZ setup menu ; just
select the other units present in the Media Source list
of the Camera Tree menu, one at a time, and check
Enable PTZ, then click on Apply.
Fig. 127
When the unit settings have been inserted,
quit the NVR programm and re-start it so
that all the changes will be saved.
To control a unit via the control panel, select the unit
to be controlled by clicking with the mouse on the
corresponding video window, and then operate from
the control panel .
Fig. 128
It is possible to set 5 different speeds for pan and tilt
and it is also possible to enable advanced functions
using the Action menu (which contains, for example,
the Autopan, Start, Stop commands etc.). If you want
to control the PTZ using the mouse, directly from
the video window, check Mouse PTZ in the control
panel. You can then use the mouse to control both
movements and zoom (Zoom + and Zoom - are
situated in the centre).
Mouse PTZ
Fig. 129
