Videotec MAXIMUS MPXT - Manual (Page 60)

EN - English - I
nstruc
tions manual
58
Continue by pressing the Install button. You carry out
this procedure once and only once for each PC that is
to have access to the device in the network.
The Live Video window will then appear.
Fig. 115
To make the parameter settings, click on the Quit
button next to the video display. The general
parameter setting menu will then appear.
Fig. 116
9.7.2.1 WAN setting
Keep the account and the password in a
secure place.
Next, set the static IP address, which is used to
gain access to the unit that is to be configured. For
example, set a static IP and address 192.168.0.101.
Fig. 117
Next, click on Apply and then click on Save & Reboot.
Wait about 30 seconds, until the settings have been
saved. Re-connect to the modified address (e.g.
192.168.0.101), inserting the Account Name and
Password (use the default settings if they have not
been changed).
