14 Technical data
If the equipment is likely to come into contact with
aggressive substances, then it is the responsibility of
the user to take suitable precautions that prevent it
from being adversely affected, thus ensuring that the
type of protection is not compromised.
Aggressive substances: Acidic liquids or gases
that may attack metals, or solvents that may affect
polymeric materials.
Suitable precautions: Regular checks as part of
routine inspections or establishing from the material’s
data sheet that it is resistant to specific chemicals.
It is the end users responsibility to ensure the
materials of construction as detailed are suitable for
the intended point of installation. If in doubt consult
the manufacturer.
14.1 MPX
14.1.1 General
AISI 316L stainless steel construction
Passivated and electropolished external surfaces
RTV silicone rubber
NBR rotary seals
Silicone O-ring seals
Quick configuration and setup
Dynamic positioning control system
14.1.2 Mechanical
1 3/4" NPT hole for cable glands
Zero backlash
Horizontal rotation: 360° continous
Vertical rotation: -90° to +90°
Variable pan speed: from 0.1° to 100°/s
Variable tilt speed: from 0.1° to 100°/s
Preset accuracy: 0.02°
12mm thick tempered glass window
Integrated Wiper
14.1.3 Electrical/Video
Input voltage:
- 230Vac, 50/60Hz, 120W max
- 24Vac, 50/60Hz, 120W max
- 120Vac, 50/60Hz, 120W max
1 video output 75 Ohm 1Vpp (PAL/NTSC)
Functions: Autopan, Preset, Patrol, Tour (maximum 3),
Autoflip
Maximum number of presets:
- VIDEOTEC MACRO Protocol: 250
- ERNITEC protocol: 250
- PANASONIC protocol: 250
- PELCO D Protocol: 99
- AMERICAN DYNAMICS protocol: 95
16-character string for zone and preset titling
I/O alarm card:
- 5 alarm inputs
- 2 relay outputs (1A 30Vac/60Vdc max)
