THERMAL CAMERAS AVAILABLE (RESOLUTION 640X512)
Lens 35mm Lens 25mm Lens 19mm Lens 13mm Lens 9mm
PAL NTSC PAL NTSC PAL NTSC PAL NTSC PAL NTSC
Image sensor Uncooled VOx microbo-
lometer
Uncooled VOx microbo-
lometer
Uncooled VOx microbo-
lometer
Uncooled VOx microbo-
lometer
Uncooled VOx microbo-
lometer
Resolution 640x512 640x480 640x512 640x480 640x512 640x480 640x512 640x480 640x512 640x480
Pixel dimensions 17μm 17μm 17μm 17μm 17μm
Spectral response - long wave infrared
(LWIR)
from 7.5μm to 13.5μm from 7.5μm to 13.5μm from 7.5μm to 13.5μm from 7.5μm to 13.5μm from 7.5μm to 13.5μm
Internal shutter (only for sensor compen-
sation)
Video stop < 1sec. Video stop < 1sec. Video stop < 1sec. Video stop < 1sec. Video stop < 1sec.
Digital Detail Enhancement (DDE) • • • • •
Digital Zoom 2x, 4x 2x, 4x 2x, 4x 2x, 4x 2x, 4x
Image updating frequency 8.3fps, 25fps 7.5fps, 30fps 8.3fps, 25fps 7.5fps, 30fps 8.3fps, 25fps 7.5fps, 30fps 8.3fps, 25fps 7.5fps, 30fps 8.3fps, 25fps 7.5fps, 30fps
Scene temperature range -40°C ÷ +160°C (-40°F ÷
+320°F)
-40°C ÷ +160°C (-40°F ÷
+320°F)
-40°C ÷ +160°C (-40°F ÷
+320°F)
-40°C ÷ +160°C (-40°F ÷
+320°F)
-40°C ÷ +160°C (-40°F ÷
+320°F)
Horizontal field of view 18° 25° 32° 45° 69°
Vertical field of view 14° 20° 26° 37° 56°
F-number F/1.2 F/1.1 F/1.25 F/1.25 F/1.4
Thermal sensitivity (NEdT) < 50mK a f/1.0 < 50mK a f/1.0 < 50mK a f/1.0 < 50mK a f/1.0 < 50mK a f/1.0
Person (detection / recognition / identi-
fication)
1140m / 280m / 142m
(3740ft / 919ft / 466ft)
820m / 210m / 104m
(2690ft / 689ft / 341ft)
570m / 144m / 72m (1870ft
/ 472ft / 236ft)
390m / 95m / 47m (1280ft /
312ft / 154ft)
300m / 81m / 38m (984ft /
266ft / 125ft)
Auto (detection / recognition / identifi-
cation)
3000m / 800m / 400m
(9843ft / 2625ft / 1312ft)
2200m / 580m / 290m
(7218ft / 1903ft / 951ft)
1550m / 400m / 200m
(5085ft / 1312ft / 656ft)
1080m / 275m / 140m
(3543ft / 902ft / 459ft)
820m / 210m / 100m
(2690ft / 689ft / 328ft)
Tab. 18
