Instruc tions manual - English - EN
79
THERMAL CAMERAS AVAILABLE (RESOLUTION 160X120)
Lens 19mm Lens 13mm Lens 9mm
PAL NTSC PAL NTSC PAL NTSC
Image sensor Uncooled VOx microbolometer Uncooled VOx microbolometer Uncooled VOx microbolometer
Resolution 160x120 160x120 160x120 160x120 160x120 160x120
Pixel dimensions 25μm 25μm 25μm
Spectral response - long wave infrared (LWIR) from 7.5μm to 13.5μm from 7.5μm to 13.5μm from 7.5μm to 13.5μm
Internal shutter (only for sensor compensation) Video stop < 1sec. Video stop < 1sec. Video stop < 1sec.
Digital Detail Enhancement (DDE) • • •
Digital Zoom 2x, 4x 2x, 4x 2x, 4x
Image updating frequency 8.3fps, 25fps 7.5fps, 30fps 8.3fps, 25fps 7.5fps, 30fps 8.3fps, 25fps 7.5fps, 30fps
Scene temperature range -40°C ÷ +160°C (-40°F ÷ +320°F) -40°C ÷ +160°C (-40°F ÷ +320°F) -40°C ÷ +160°C (-40°F ÷ +320°F)
Horizontal field of view 12° 17° 25°
Vertical field of view 10° 14° 20°
F-number F/1.25 F/1.25 F/1.25
Thermal sensitivity (NEdT) < 50mK a f/1.0 < 50mK a f/1.0 < 50mK a f/1.0
Person (detection / recognition / identification) 450m / 112m / 56m (1476ft / 367ft /
184ft)
300m / 74m / 37m (984ft / 243ft / 121ft) 205m / 52m / 26m (673ft / 171ft / 85ft)
Auto (detection / recognition / identification) 1280m / 330m / 165m (4199ft / 1083ft
/ 541ft)
840m / 215m / 108m (2756ft / 705ft /
354ft)
590m / 150m / 74m (1936ft / 492ft /
243ft)
Tab. 15
