14.3 MPXT
14.3.1 General
AISI 316L stainless steel construction
Passivated and electropolished external surfaces
RTV silicone rubber
NBR rotary seals
Silicone O-ring seals
Quick configuration and setup
Dynamic positioning control system
14.3.2 Mechanical
1 3/4" NPT hole for cable glands
Zero backlash
Horizontal rotation: 360° continous
Vertical rotation: -90° to +90°
Variable pan speed: from 0.1° to 100°/s
Variable tilt speed: from 0.1° to 100°/s
Preset accuracy: 0.02°
12mm thick tempered glass window
8mm thick germanium window
Integrated Wiper
14.3.3 Electrical/Video
Input voltage:
- 230Vac, 50/60Hz, 120W max
- 24Vac, 50/60Hz, 120W max
- 120Vac, 50/60Hz, 120W max
2 video outputs 75 Ohm 1Vpp (PAL/NTSC)
Functions: Autopan, Preset, Patrol, Tour (maximum 3),
Autoflip
Maximum number of presets:
- VIDEOTEC MACRO Protocol: 250
- ERNITEC protocol: 250
- PANASONIC protocol: 250
- PELCO D Protocol: 99
- AMERICAN DYNAMICS protocol: 95
16-character string for zone and preset titling
I/O alarm card:
- 5 alarm inputs
- 2 relay outputs (1A 30Vac/60Vdc max)
