Display Items

PF3000

Application Rate Mode

Ag Leader Technology

April 2002

4-44


Introduction

The PF3000 has four display lines for viewing items. You can choose what
items you see on the display and the position that the items appear on the
display.

To change the display item on a display line you must select the line. The
four keys to the right of the display each select a display line. A rectangular
box surrounds the display line to show that that line is selected.

When the display line is selected the four menu items on the bottom change
and show items you can select for display. Press a key below a display item
to put a different display item in place of the selected display item. There
are more than four display items to choose for viewing. Press the bottom
LEFT or RIGHT ARROW keys to scroll to the right or left and view other
display items on the bottom.

When some display items (like swath) are selected, an up and down arrow
symbol will appear on the right of the display line. This indicates you can
change the setting of the item with the UP or DOWN ARROW keys. After
you have made the change you must press the key to the right of the display
line to deselect the line.

Field and Load
Totals

When the following are displayed you can see a field or load total.
Actual Rate
Total Units
Area
Distance

To view a field total you must have the field displayed with out the load.
Press the FIELD key to display the field alone on the top line. To view a
load total, you must have the load displayed with the field on the top line.
Press the LOAD key to display the load on the top line.
