Calibrating Distance

Ag Leader Technology

(All Modes)

April 2002

3-3

Preparing to
Calibrate Distance

You must accurately measure a known distance, setting flags or making a
mark at each end of the path.

NOTE:

Use at least a 200 feet travel path to obtain an accurate calibration.

For maximum accuracy, calibrate on a ground surface that is similar to
field conditions.

Example of distance calibration screen:

Calibration

DISTANCE CALIBRATION: WHEEL

Procedure

ACTUAL DISTANCE:

200

ft

MEASURED DISTANCE

:

0

ft

PULSES / 100 FT:

2000

START

TRAVEL

CLEAR

DISTANCE

PERFORM

CAL

EXIT





STOP

CANCEL

TRAVEL
