PF3000

Diagnostic

Ag Leader Technology

All Modes

April 2002

4-23

Introduction

The diagnostic screens provide troubleshooting and reference information
for the PF3000.

Diagnostic Screens

To view the diagnostic screens press the:

MENU key

DIAG key

Press the SYSTEM or YIELD or GPS or RAW NMEA key.

Press the EXIT key when you are finished viewing the screen.

The following are examples of diagnostic screens:


SYSTEM DIAGNOSTICS

Hardware revision

1.60

Serial number

980034

ROM version

2.10

Program version

2.60

Operating memory

18352 bytes

Storage memory

519632 bytes

Vehicle battery

14.9 volts

EDIT

FORMAT

CARD

COPY TO

CARD

EXIT


The yield diagnostic screen is not present in the application rate or site
verification mode.

YIELD DIAGNOSTICS

Min / Max

56797 / 52237

Moisture Sensor

0 - - 6.8%

Flow offset

300

Sensor force

0 lb

Ground speed

0 mph

Elevator speed

0 rpm

Header position

0

Temperature offset

-3

EXIT
