Calibrating Stop Height

PF3000

(Harvest Mode)

Ag Leader Technology

April 2002

3-20

Step

Action

1

Use the UP or DOWN ARROW keys to select the grain.

2

Press the ENTER HEIGHT key.

STOP HEIGHT CALIBRATION: SOYBEANS

STOP HEIGHT SETTING:

0

CURRENT STOP HEIGHT:

60

SET

HEIGHT

CAL

C1

CAL

DISTANCE

EXIT

Step

Action

3

Move the combine head to the height at which you want the monitor
to stop counting area.

4

Press the SET HEIGHT key. The monitor will automatically set the
stop height setting equal to the current stop height. Press the
ACCEPT key.

5

Press the EXIT key twice to return to the main operating screen.


NOTE: You can manually adjust the stop height number by pressing the
UP or DOWN ARROW key when the screen above is displayed.

* * *
