Monitoring and managing the Director

72

Director Element Manager User Guide

Director Speed—For the Director 2/140 model, this is always

2 Gig

. For the

Director 2/64 model, this speed is configured through the Configure Switch
Parameters dialog box and can be either

1 Gig

or

2 Gig

.

Switch Binding—Displays

Enabled

if the optional SANtegrity Binding

features are installed and enabled. Otherwise, displays

Disabled

.

You can also display the Director Properties dialog box by right-clicking the
director illustration away from an FRU and choosing Properties from the menu.

Using Menu Options

Right-click various parts of the Hardware View to display pop-up menu options
for displaying status and information and for controlling the director and its FRUs.
The following menus are available:

Director

Port Card

CTP Card

SBAR Card

Director Menu

Right-click any area of the director illustration where a hardware component is
not installed to display the following menu options:

Properties—Click this option to display the Director Properties dialog box.
See details under “

Displaying Director Information

” on page 71. You can also

display this dialog box by double-clicking an area on the director illustration,
but not on a hardware component.

Enable Unit Beaconing—Click this option to toggle unit beaconing on or
off. When the check box has a check mark, unit beaconing is on, and the
amber system error light on the director front bezel blinks to help users locate
the actual unit in an equipment room. When you click the check box to
remove the check mark, unit beaconing is disabled and the amber LED goes
out.

Note:

You can only enable beaconing if there are no system errors (the system error

light is off).
