Monitoring and managing the Director

110

Director Element Manager User Guide

Not

Operational

Off

Off

Yellow

Triangle

The director port is receiving the Fibre

Channel not operational sequence (NOS),

indicating that the attached device is not

operational.

Online

On

Off

None

The attached device has successfully

connected to the director and is ready to

communicate or is in the process of

communicating with other attached devices.

As long as the port remains online, the

green port LED remains illuminated. Note

that on the actual port in the unit, the green

LED blinks when there is active Fibre

Channel traffic through the port.

Offline

Off

Off

None

The director port was configured as

blocked

and is transmitting the Fibre Channel OLS to

the attached device.

Off

Off

Yellow

Triangle

The director port was configured as

unblocked

and is receiving the Fibre

Channel OLS, indicating that the attached

device is offline.

Port Failure

Off

On

Red and

Yellow

Blinking

Diamond

The director port has failed and requires

service. The amber LED for the port remains

illuminated.

Segmented

E_Port

On

Off

Yellow

Triangle

The E_Port is segmented preventing the two

fabrics from joining (this only occurs when

two directors are connected to each other).

Display the Port Properties dialog box to

view the segmentation reason.
