Overview
29
Director Element Manager User Guide
■
FICON. Typically, click this option button when attaching an IBM S/390
Parallel Enterprise or zSeries server to the director and implementing inband
director management through a Fibre Connection (FICON) channel. If
director firmware level is below 6.0 and the FICON Management Server
feature is enabled, the default management style will be FICON. The
management style can be changed to Open Systems with the FICON
Management Server feature enabled.
Note:
If firmware versions below 6.0 are installed on the director, you need to take the
director offline before changing the management style.
Port
This option provides a secondary port menu only when the Port Card View, Port
List View, or Performance View displays in the View panel. To use this menu for a
specific port, click a port in the Port Card View, a port’s row in the Port List View,
or a port’s bar graph in the Performance View.
The menu contains options that are identical to those that display when you
right-click a port, port row, or port bar graph in those views. For details on these
options, see “
FRU
Click a serial crossbar (SBAR) card, control processor (CTP) card, port card,
power supply module, or cooling fan module in the Hardware View only and then
click Product > FRU to display a menu of options for the selected FRU. These
options are the same menu options that display when you right-click these
components in the Hardware View. For details on these options, see the following
sections in “
■
■
■
