Overview

27

Director Element Manager User Guide

Figure 4: Director 2/140 Element Manager window

Note:

The HAFM application window is available as a separate window. You can

drag the Element Manager window away from the HAFM application window and

view both windows on your desktop or minimize one or both of them to icons if desired.

You can have a maximum of four Element Manager windows open concurrently.

1

Menu bar

2

View tabs

3

View panel

4

Status bar

3

1

2

4
