Overview

26

Director Element Manager User Guide

Note:

Figure 3

displays the Director 2/64 Hardware View and

Figure 4

displays the

Director 2/140 Hardware View. Other views may display, depending on what you

displayed last before closing the Element Manager.

Figure 3: Director 2/64 Element Manager window

1

Menu Bar

2

View tabs

3

View panel

4

Status bar

2

1

3

4
