Configuring the Director

139

Director Element Manager User Guide

3. Click the check box in the Blocked column to block or unblock operation for

a port.

4. Click the check box in the 10-100 km column to enable or disable extended

distance buffering for the port.

5. Click the check box in the LIN Alerts column to enable or disable LIN alerts

for the port.

Note:

The factory default for LIN alerts is enabled.

6. Click the Type field to choose a port type.

7. Click the check box in the Port Binding column to prevent an unspecified

device from being connected to the port when you.

8. Click in the Speed column for the port and click 1 Gig, 2 Gig, or Negotiate to

set the data speed for the port. When you click Negotiate, it allows the port
and attached device to negotiate the data rate.

Note:

Your director model, firmware, and port card may not allow 2 Gb/s data

speeds.

9. Click the Bound WWN field and enter the WWN or nickname of the specific

device to be connected to the port.

10. Use the scroll bar on the right side of the Configure Ports dialog box table to

display additional ports that you want to configure.

11. Click Activate to activate the changes and close the dialog box.

12. If you are finished configuring the switch, back up the configuration data. For

more information, see “

Backing Up and Restoring Configuration Data

” on

page 164.
