Overview
54
Director Element Manager User Guide
Closing the Element Manager
To close the Element Manager, do one of the following:
■
Click Product > Close on the menu bar.
■
Double-click the icon at the top left corner of the Element Manager window,
or click the icon and click Close on the menu that displays.
Feature Permissions
The system administrator can allow users access to specific functions of Element
Manager features through HAFM.
The HP StorageWorks HA-Fabric Manager User Guide provides detailed
instructions for assigning permissions.
There are three permission levels that can be assigned to specific users:
■
Device Administration
■
Device Operation
■
Device Maintenance
Red and
Yellow
Diamond
NOT OPERATIONAL
A critical failure prevents the
director from performing
fundamental switching operations.
All fans fail.
Both SBAR cards fail.
All installed Port cards fail.
Gray
Square
Never Connected
Link Timeout
Protocol Mismatch
Duplicate Session
Unknown Network
Address
Incorrect Product Type
Director status is unknown. This
occurs if the Ethernet network
connection between the HAFM
appliance and the director cannot
be established or if the CTP fails.
page 63 for details on the status
table text.
Table 2: Operating status—status bar and director Status table (Continued)
Symbol
Status
bar
Director Status table
text
Meaning
