Teledyne LeCroy Properties Dialog Boxes for Events
78 Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual
5.21 Properties Dialog Boxes for Events
Properties dialog boxes provide additional settings for Events, States, and Actions in the
Recording Rules page. You can access a Properties dialog by double‐clicking an Event,
State, Action or any other object. It allows you to set triggers and filters. For example, to
set a trigger on a specific type of error, you open the Properties dialog.
5.21.1 Accessing the Properties Dialog
To see the Properties dialog, first create an event button by clicking the New Events
button and choosing an event from the menu. Open the Event Properties dialog by doing
one of the following:
 Double‐click an event.
 Right‐click an event and select Properties from the pop‐up menu.
 Click the Properties button on the toolbar.
5.21.2 Event Properties Dialog Box Features
The following features are displayed in the any Event Properties dialog box (see
Figure 5.28 on page 79 ).
Event Icon Preview
This icon shows you which event properties you are editing. The Icon Preview looks
exactly like the icon in the Main Display area.
Icon Label
A text box for labeling the button. Whatever you type here appears on the button.
Channels
These controls allow you to select the channel(s) that the Analyzer should search when it
is looking for the event.
Pin Button
The Pin Button on the top right corner of the dialog allows you to pin the Properties
dialog to the application so that it does not go away when another object appears such as
an event, state or action.
AHCI
AHCI Register
ATA Command
NVME
NVME Register
NVME Command Submission
NVME Command Completion
TABLE 5.3: Events and Event Actions
