Recording Rules Events
Teledyne LeCroy
Speed Change to 2.5Gb/s
Speed Change to 5.0Gb/s
Ordered Set
TS1
TS2
EIEOS
EIOS
Skip
FTS
Errors
Idle Error
Disparity Error
Symbol Error
DLLP
Generic (User‐definable)
Any DLLP
MR DLLP
InitFC1
InitFC2
UpdateFC
ACK
NAK
Power Management
Vendor
TLP
Generic (User‐definable)
Any TLP
Config Rd
Config Wr
IO Rd
IO Wr
Mem Rd
Mem Wr
Message
Completion
TABLE 5.3: Events and Event Actions
