Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual 179
Bus Utilization Teledyne LeCroy
Figure 10.13: Graph Area Properties Dialog
10.4.2 Bus Utilization Buttons
The Bus Utilization window buttons allow you to reformat the display and export data.
Button Function
Save. Saves Bus Utilization data to a bitmap file (*.bmp).
Email. Opens an email and attaches a bitmap file of the Bus
Utilization data.
