Teledyne LeCroy

Using the Menus

28

Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual

4.5.5

Search Menu

Search Menu operations are only available when you are working with a CATC Trace file.

Trace
Navigator

Shows the Navigator bar for navigating a CATC Trace. Shows a
snapshot of the recording and allows you to adjust the memory
area for the view.

LTSSM Flow
Graph

Shows a state diagram of bus activity. Also allows you to navigate
through the LTSSM, based on the current recording.

Packet Header

Opens the Packet Header bar, showing the Packet Header
information as it would be viewed in the specification.

Packet Data

Opens the Data Window for the current packet or transaction, with
the options: Hide, Save, Hexadecimal, ASCII, Decimal, Binary,
MSB Format, LSB Format, Big Endian, and Little Endian. Format Line
allows you to enter the number of bytes, words, or dwords per line.

Configuration
Space

Presents a list of Configuration Spaces. Clicking an item displays the
selected Configuration Space in a Configuration Table format.

Go to Trigger

Repositions the display to show the first packet following the
trigger event.

Go to
Segment/
Packet

Repositions the display to a specific packet, Link or Split transaction
of PCI Express protocol or NVME, PQI, AHCI protocol and ATA
command transactions number.

Go to Time

Repositions the display to specific timestamp.

Go to Marker

Repositions the display to a previously marked packet, Link, Split,
NVME, or ATA command transactions.

Go to

Allows searching for specific link events: TLP Type, DLLP Type,
Ordered Set, Link Event, Traffic Class, DLLP Virtual Channel,
TLP Virtual Channel, Direction, Speed, Link Width, Requester ID,
Completer ID, Data Lengths, Errors.
