Teledyne LeCroy Spreadsheet View
116 Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual
6.12.2 Rows
To manipulate rows, right‐click the left‐most column gray area to display the following
commands:
Display Options Opens the Display Options menu
(see
“Display Options” on page 145 ).
CATC Walk See and manage playlists.
(see
“CATC Walk Playlist” on page 134 ).
Real‐time Statistics Allows you to view traffic statistics as they occur.
See
“Real‐Time Statistics Window” on page 206 .
Zoom In Zoom in increases the size of the displayed elements.
Zoom Out Zoom out decreases the size of the displayed elements.
Wrap Wraps displayed packets within the window.
Synchronize Trace
View With Other
Views Synchronizes the Trace view with other views.
FC Credits Toggles a display for tracking Flow Control Credit update and
consumption on a PCI Express link.
(see
“Flow Control Tracking” on page 187 ).
FC Credits Setup Allows you to customize the display for tracking Flow Control
Credits (see
“Flow Control Tracking” on page 187 ).
Compact View Toggles compacting of the Link Training sequence to analyze
CATC Trace data faster or no compacting to display more data.
Packet Level View the current recording at the Packet Level.
Link Transaction
Level View the current recording at the Link Transaction Level.
Split Transaction
Level View the current recording at the Split Transaction Level.
NVM Transaction
Level View the current recording at the NVM Transaction Level.
PQI Transaction
Level View the current recording at the PQI Transaction Level.
ACHI Transaction
Level View the current recording at the ACHI Transaction Level.
ATA Transaction
Level View the current recording at the ATA Transaction Level.
