Data Flow Window
186
Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual
10.6 Data Flow Window
The Data Flow window shows marker, packet, direction, type, length, address, payload,
handshake, and timestamp information.
To obtain the Data Flow window, select Report > Data Flow
or click the
Data Flow toolbar icon.
Figure 10.15: Data Flow Window
Collapse Idle Plus. Do not show periods of Link being idle.
Show Values
Show Scrambled Values
Show 10b Codes
Show Symbols
Show Text
