Teledyne LeCroy Using Probes
14 Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual
3.7 Using Probes
3.7.1 Example: Connecting the Summit T28 Analyzer to the Device Under Test
Using a Gen2 MidBus Probe
Note: Mid‐bus probes require attachment‐pad and reference‐clock connections. For information
about how to connect the attachment pad, reference clock, and cables in your system, see the
MidBus Probe Manual.
Components
Figure 3.7: iPass Y-cable
Figure 3.8: MidBus Probe pod
Figure 3.9: Half-size Gen2 Mid-bus Probe Cable and Header Assembly
