34 Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual
4.7 Tool Tips
Tool tips provide details about fields within the CATC Trace. To see a tool tip, position your
mouse pointer over a field within the CATC Trace.
You can turn off this capability in the Display Options menu.
4.8 Keyboard Shortcuts
4.9 Status Bar
The Status Bar is a gray bar that runs along the bottom of the application window.
From left to right:
PETracer SN:309: Analyzer Serial Number
Ready: Analyzer Status
Keystrokes Operation
Ctrl + N New PETracer script
Ctrl+O Open file
Ctrl+P Print
Ctrl+S Save file
Ctrl + R Start Analyzer recording
Ctrl + T Stop Analyzer recording
Ctrl+Home Jump to first packet
Ctrl+End Jump to last packet
Ctrl + G Go to packet ...
Ctrl + F Search forward
F1 Access documentation
F3 Find next
F6 Next pane
Shift+F6 Previous pane
Ctrl+B Search backward
