Teledyne LeCroy Triggering
60 Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual
5.15.1 Triggering On (Simple Mode)
You can check any of the boxes shown in Table 5.1 for Trigger On in Simple Mode (see
Figure 5.14 on page 61 ).
Trigger Position is only available when Event Trigger or Bit Tracer Recording is selected.
Note: If you check 2 boxes or more the triggering will occur based on an OR condition, not AND
condition.
Note: External Input Trigger is not configurable, it will always cause the analyzer to trigger on a toggle
when using manual trigger or triggering on any event.
TABLE 5.1: Simple Mode Trigger On Events
Enter Elec Idle AnyTLP
Exit Elec Idle Config
Switch to G1 Memory
Switch to G2 IO
TS1 RD Error
TS2 Invalid Symbol
InitFC1 Block Align Error
NAK Token Error
PM Idle Symbol Error
