Teledyne LeCroy Probe Settings
102 Summit T28 PCI Express Multi‐Lane Protocol Analyzer User Manual
5.26.2 Load
The Load function in the Recording Rules and the Probe settings tab has the following
options (see
Figure 5.55 on page 102 ):
 Load the whole Recording Options (.rec)
 Load the Recording Options of a PCIe Trace File (.pex)
 Load only the Recording Rules portions of the recording options (.rr)
 Load only the Probe Settings portions of the recording options (.ps)
Figure 5.55: Load Dialog
