Multicast Filtering Commands
4-397
4
Example
The following shows the global MVR settings:
The following displays information about the interfaces attached to the MVR VLAN:
Console#show mvr
MVR Status:enable
MVR running status:TRUE
MVR multicast vlan:1
MVR Max Multicast Groups:255
MVR Current multicast groups:10
MVR Receiver VLAN:3
MVR Supported Receiver Multicast Groups:5
MVR Used Receiver Multicast Groups:1
Console#
Table 4-96 show mvr - display description
Field Description
MVR Status Shows if MVR is globally enabled on the switch.
MVR Running Status Indicates whether or not all necessary conditions in the MVR environment
are satisfied.
MVR Multicast VLAN Shows the VLAN used to transport all MVR multicast traffic.
MVR Max Multicast Groups Shows the maximum number of multicast groups which can assigned to the
MVR VLAN.
MVR Current Multicast
Groups
Shows the number of multicast groups currently assigned to the MVR VLAN.
MVR Receiver VLAN VLAN used to froward multicast traffic with tagged frames without revealing
the identity of the MVR VLAN
MVR Supported Receiver
Multicast Groups
Number of multicast groups to be managed through the receiver VLAN
MVR Used Receiver Multicast
Groups
Number of multicast groups currently active within the receiver VLAN
Console#show mvr interface
Port Type Status Immediate Leave
------- -------- ------------- ---------------
eth1/1 SOURCE ACTIVE/UP Disable
eth1/2 RECEIVER ACTIVE/UP Disable
eth1/5 RECEIVER INACTIVE/DOWN Disable
eth1/6 RECEIVER INACTIVE/DOWN Disable
eth1/7 RECEIVER INACTIVE/DOWN Disable
Console#
Table 4-97 show mvr interface - display description
Field Description
Port Shows interfaces attached to the MVR.
Type Shows the MVR port type.
