Authentication Commands
4-153
4
- server-timeout – Server timeout.
- reauth-max – Maximum number of reauthentication attempts.
- max-req – Maximum number of times a port will retransmit
an EAP request/identity packet to the client
before it times out the authentication session
(page 4-146).
- Status – Authorization status (authorized or not).
- Operation Mode – Shows if single or multiple hosts (clients) can
connect to an 802.1X-authorized port.
- Max Count – The maximum number of hosts allowed to
access this port (page 4-147).
- Port-control – Shows the dot1x mode on a port as auto,
force-authorized, or force-unauthorized
(page 4-146).
- Supplicant – MAC address of authorized client.
- Current Identifier – The integer (0-255) used by the Authenticator to
identify the current authentication session.
- Intrusion action – Shows whether the switch will block all non-EAP
traffic or assign traffic on the port to a guest
VLAN if authentication fails.
• Authenticator State Machine
- State – Current state (including initialize, disconnected,
connecting, authenticating, authenticated, aborting,
held, force_authorized, force_unauthorized).
- Reauth Count – Number of times connecting state is re-entered.
• Backend State Machine
- State – Current state (including request, response,
success, fail, timeout, idle, initialize).
- Request Count – Number of EAP Request packets sent to the
Supplicant without receiving a response.
- Identifier(Server) – Identifier carried in the most recent EAP Success,
Failure or Request packet received from the
Authentication Server.
• Reauthentication State Machine
- State – Current state (including initialize, reauthenticate).
