Configuring the Switch
3-286
3
• New Multicast Address Range List – Specifies multicast groups to include in the
profile. Specify a multicast group range by entering a start and end IP address.
Specify a single multicast group by entering the same IP address for the start and
end of the range. Click the Add button to add a range to the current list.
• Current Multicast Address Range List – Lists multicast groups currently
included in the profile. Select an entry and click the Remove button to delete it from
the list.
Web – Click IGMP Snooping, IGMP Filter Profile Configuration. Select the profile
number you want to configure; then click Query to display the current settings.
Specify the access mode for the profile and then add multicast groups to the profile
list. Click Apply.
Figure 3-164 IGMP Profile Configuration
CLI – This example configures profile number 19 by setting the access mode to
“permit” and then specifying a range of multicast groups that a user can join. The
current profile configuration is then displayed.
Console(config)#ip igmp profile 19 4-386
Console(config-igmp-profile)#permit 4-386
Console(config-igmp-profile)#range 239.1.2.3 4-387
Console(config-igmp-profile)#range 239.2.3.1 239.2.3.200
Console(config-igmp-profile)#end
Console#show ip igmp profile 19
4-390
IGMP Profile 19
permit
range 239.1.2.3 239.1.2.3
range 239.2.3.1 239.2.3.200
Console#
