LevelOne FGL-2870 - Manual (Page 361)

Switch Clustering
3-307
3
Cluster Member Configuration
Adds Candidate switches to the cluster as Members.
Command Attributes
• Member ID – Specify a Member ID number for the selected Candidate switch.
(Range: 1-36)
• MAC Address – Select a discovered switch MAC address from the Candidate
Table, or enter a specific MAC address of a known switch.
Web – Click Cluster, Member Configuration.
Figure 3-179 Cluster Member Configuration
CLI – This example creates a new cluster Member by specifying the Candidate
switch MAC address and setting a Member ID.
Console(config)#cluster member mac-address 00-12-34-56-78-9a id 5 4-83
Console(config)#end
Console#show cluster candidates
4-84
Cluster Candidates:
Role Mac Description
--------------- ----------------- ------------------------------------
ACTIVE MEMBER 00-12-cf-23-49-c0 FGL-2870
CANDIDATE 00-12-cf-0b-47-a0 FGL-2870
Console#
