Main Menu
3-9
3
Tunnel Port Configuration
Sets the tunnel mode for an interface
Tunnel Trunk Configuration Sets the tunnel mode for an interface
Traffic Segmentation
Configures traffic segmentation for different client sessions
based on specified downlink and uplink ports
Status
Enables traffic segmentation, and blocks or forwards traffic
between uplink ports assigned to different client sessions
Session Configuration
Creates a client session, and assigns the downlink and uplink
ports to service the traffic
Private VLAN
Information
Displays Private VLAN feature information
Configuration
This page is used to create/remove primary or community
VLANs
Association
Each community VLAN must be associated with a primary VLAN
Port Information
Shows VLAN port type, and associated primary or secondary
VLANs
Port Configuration
Sets the private VLAN interface type, and associates the
interfaces with a private VLAN
Trunk Information
Shows VLAN port type, and associated primary or secondary
VLANs
Trunk Configuration
Sets the private VLAN interface type, and associates the
interfaces with a private VLAN
Protocol VLAN
Configuration
Creates a protocol group, specifying the supported protocols
System Configuration
Configures protocol VLAN system parameters
IP Subnet VLAN
Configuration
Maps IP subnet traffic to a VLAN
MAC Based VLAN
Configuration
Maps traffic with specified source MAC address to a VLAN
VLAN Mirror Configuration
Sets source VLANs and a target port for mirroring
LLDP
Link Layer Discovery Protocol
Configuration
Configures global LLDP timing parameters
Port Configuration
Configures parameters for individual ports
Trunk Configuration
Configures parameters for trunks
Local Information
Displays LLDP information about the local device
Remote Port Information
Displays LLDP information about a remote device connected to
a port on this switch
Table 3-2 Main Menu (Continued)
Menu
Description
Page
