Command Line Interface
4-322
4
protocol-vlan protocol-group (Configuring Groups)
This command creates a protocol group, or adds specific protocols to a group. Only
one frame type and protocol type can be added to a protocol group. Use the no form
to remove a protocol group.
Syntax
protocol-vlan protocol-group group-id [{add | remove} frame-type frame
protocol-type protocol]
no protocol-vlan protocol-group group-id
• group-id - Group identifier of this protocol group. (Range: 1-2147483647)
• frame
29 - Frame type used by this protocol. (Options: ethernet, rfc-1042,
llc-other)
• protocol - Protocol type. The only option for the llc-other frame type is
ipx-raw. The options for all other frames types include: ip, arp, and rarp.
Default Setting
No protocol groups are configured.
Command Mode
Global Configuration
Example
The following creates protocol group 2, and specifies Ethernet frames transmitting
ARP protocol type traffic:
protocol-vlan protocol-group (Configuring VLANs)
This command globally maps a protocol group to a VLAN. Use the no form to
remove the protocol mapping.
Syntax
protocol-vlan protocol-group group-id vlan vlan-id
no protocol-vlan protocol-group group-id vlan
• group-id - Group identifier of this protocol group. (Range: 1-2147483647)
• vlan-id - VLAN to which matching protocol traffic is forwarded.
(Range: 1-4094)
Default Setting
No protocol groups are mapped to any VLANs.
Command Mode
Global Configuration
29. SNAP frame types are not supported by this switch due to hardware limitations.
Console(config)#protocol-vlan protocol-group 2 add frame-type ethernet
protocol-type arp
Console(config)#
