Port Configuration
3-157
3
Current Status:
• Link Status – Indicates if the link is up or down.
• Port Operation Status – Provides detailed information on port state.
(Displayed only when the link is up.)
• Operation Speed-duplex – Shows the current speed and duplex mode.
• Flow Control Type – Indicates the type of flow control currently in use.
(IEEE 802.3x, Back-Pressure or none)
CLI – This example shows the connection status for Port 5.
Configuring Interface Connections
You can use the Port Configuration or Trunk Configuration page to enable/disable an
interface, set auto-negotiation and the interface capabilities to advertise, or manually
fix the speed, duplex mode, and flow control.
Command Usage
• Auto-negotiation must be disabled before you can configure or force the interface
to use the Speed/Duplex Mode or Flow Control options.
• When using auto-negotiation, the optimal settings will be negotiated between the
link partners based on their advertised capabilities. To set the speed, duplex mode,
or flow control under auto-negotiation, the required operation modes must be
specified in the capabilities list for an interface.
• The 1000BASE-T standard does not support forced mode. Auto-negotiation
should always be used to establish a connection over any 1000BASE-T port or
Console#show interfaces status ethernet 1/5 4-229
Information of Eth 1/5
Basic Information:
Port Type: 100TX
MAC Address: 00-12-CF-BE-21-DE
Configuration:
Name:
Port Admin: Up
Speed-duplex: 100full
Capabilities: 100full
Broadcast Storm Limit: 64 Kbits/second
Multicast Storm: Disabled
Multicast Storm Limit: 64 Kbits/second
Unknown Unicast Storm: Disabled
Unknown Unicast Storm Limit: 64 Kbits/second
Flow Control: Disabled
VLAN Trunking: Disabled
LACP: Disabled
Port Security: Disabled
Max MAC Count: 0
Port Security Action: None
Media Type: None
Giga PHY Mode: Auto preferred master
Current Status:
Link Status: Down
Operation Speed-duplex: 100full
Flow Control Type: None
Console#
