show protocol-vlan protocol-group-vid
This command shows the mapping from protocol groups to VLANs.
Syntax
show protocol-vlan protocol-group-vid
Default Setting
The mapping for all protocol groups is displayed.
Command Mode
Privileged Exec
Example
This shows that traffic matching the specifications for protocol group 2 will be
mapped to VLAN 2:
Configuring IP Subnet VLANs
When using IEEE 802.1Q port-based VLAN classification, all untagged frames
received by a port are classified as belonging to the VLAN whose VID (PVID) is
associated with that port.
When IP subnet-based VLAN classification is enabled, the source address of
untagged ingress frames are checked against the IP subnet-to-VLAN mapping table.
If an entry is found for that subnet, these frames are assigned to the VLAN indicated
in the entry. If no IP subnet is matched, the untagged frames are classified as
belonging to the receiving port’s VLAN ID (PVID).
Console#show protocol-vlan protocol-group-vid
ProtocolGroup ID VLAN ID
------------------ -----------
2 VLAN2
Console#
Table 4-80 IP Subnet VLAN Commands
Command Function Mode Page
subnet-vlan Defines the IP Subnet VLANs GC 4-325
show subnet-vlan Displays IP Subnet VLAN settings PE 4-325
