Main Menu
3-7
3
ARP Inspection Validates the MAC-to-IP address bindings in ARP packets 3-136
Configuration Enables inspection globally and per VLAN, specifies ACL filter
containing address bindings, configures validation of additional
address components, sets trust mode for ports, and sets rate
limit for packet inspection
3-124
Information Displays information on results of inspection process 3-135
IP Filter Sets IP addresses of clients allowed management access via
the web, SNMP, and Telnet
3-107
Port 3-155
Port Information Displays port connection status 3-155
Trunk Information Displays trunk connection status 3-155
Port Configuration Configures port connection settings 3-157
Trunk Configuration Configures trunk connection settings 3-157
Trunk Membership Specifies ports to group into static trunks 3-161
LACP Link Aggregation Control Protocol 3-162
Configuration Allows ports to dynamically join trunks 3-162
Aggregation Port Configures parameters for link aggregation group members 3-164
Aggregator Configures the administration key for specific LACP groups 3-166
Port Counters Information Displays statistics for LACP protocol messages 3-167
Port Internal Information Displays settings and operational state for the local side 3-168
Port Neighbors Information Displays settings and operational state for the remote side 3-170
Port Broadcast Control Sets the broadcast storm threshold for each port 3-172
Trunk Broadcast Control Sets the broadcast storm threshold for each trunk 3-172
Port Multicast Control Sets the multicast storm threshold for each port 3-172
Trunk Multicast Control Sets the multicast storm threshold for each trunk 3-172
Port Unknown Unicast Control Sets the unknown unicast storm threshold for each port 3-172
Trunk Unknown Unicast Control Sets the unknown unicast storm threshold for each trunk 3-172
Mirror Port Configuration Sets the source and target ports for mirroring 3-177
MAC Mirror Configuration Sets a MAC address for packets to be mirrored from any source
port other thn the target port to the specified destination port
3-178
Rate Limit 3-179
Input Port Configuration Sets the input rate limit for each port 3-179
Input Trunk Configuration Sets the input rate limit for each trunk 3-179
Output Port Configuration Sets the output rate limit for ports 3-179
Table 3-2 Main Menu (Continued)
Menu Description Page
