FEC FUSION Operations Manual Chapter 4: System Setup and Wiring (Rev. 2.1)
Page 4-53
DeviceNet Signal I/O Map
(Continued)
Data Bit No. Signal Description Comment
2
0 65 Angle Integer bit 0
Outputs Fastening Angle value using
binary integer
0 - 9999 max.
Example:
bit 1, 2, 5, 7 Logical "1" = 166
1 66 Angle Integer bit 1
2 67 Angle Integer bit 2
3 68 Angle Integer bit 3
4 69 Angle Integer bit 4
5 70 Angle Integer bit 5
6 71 Angle Integer bit 6
7 72 Angle Integer bit 7
2
8 73 Angle Integer bit 8
9 74 Angle Integer bit 9
10 75 Angle Integer bit 10
11 76 Angle Integer bit 11
12 77 Angle Integer bit 12
13 78 Angle Integer bit 13
14 79
15 80
Data
2-3
16 81
Not Used
31 128
From PLC to Fusion: 2 Words (4 Bytes – 32bits)
Data Bit No. Description Comment
0
0 1
1 2
2 3
3 4
4 5
5 6
6 7 Abort Job Reserved for Future Use
7 8 Reset
0
8 9
9 10
10 11
11 12
12 13 Work Select/Job 0 Job Function is Future
13 14 Work Select/Job 1 Job Function is Future
14 15 Work Select/Job 2 Job Function is Future
15 16 Work Select/Job 3 Job Function is Future
0
16 17 Stop
17 18 Reset
18 19 Reverse
19 20 Start
20 21 Bypass
21 22 Disable Self-check
22 23
23 24
0
24 25
25 26
26 27
27 28
28 29 In 12 Terminal Input 12 not assigned
29 30 In 13 Terminal Input 13 not assigned
30 31 In 14 Terminal Input 14 not assigned
31 32 In 15 Terminal Input 15 not assigned
